Atmel AT90SCR100LSD-Z1T
- Mfg. Part Number
- AT90SCR100LSD-Z1T
- Manufacturer
- Atmel
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 64KB FLASH 32VQFN
- Datasheet Download
- AT90SCR100LSD-Z1T.pdf
Availability of AT90SCR100LSD-Z1T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AT90SCR100LSD-Z1T, we specialize in Atmel all series electronic components. AT90SCR100LSD-Z1T can be shipped within 24 hours after order. If you have any demands for AT90SCR100LSD-Z1T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AT90SCR100LSD-Z1T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AT90SCR100LSD-Z1T
| Internal Part Number | EIS-AT90SCR100LSD-Z1T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | AVR® 90SCR | |
| Packaging | Tray | |
| Core Processor | AVR | |
| Core Size | 8-Bit | |
| Speed | 48MHz | |
| Connectivity | I²C, SmartCard, SPI, UART/USART, USB | |
| Peripherals | Brown-out Detect/Reset, DMA, LED, POR, PWM, WDT | |
| Number of I/O | - | |
| Program Memory Size | 64KB (64K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 4K x 8 | |
| RAM Size | 4K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.4 V ~ 5.5 V | |
| Data Converters | - | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 32-VQFN Exposed Pad | |
| Supplier Device Package | 32-QFN (5x5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AT90SCR100LSD-Z1T | |
| Related Links | AT90SCR1, AT90SCR100LSD-Z1T Datasheet, Atmel Distributor | |
AT90SCR100LSD-Z1T Details Description
