Internal Part Number | EIS-ATS-09C-56-C2-R0 | |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | In Production | |
Condition | New & Unused, Original Sealed | |
Video File | How to Install Push Pin Heat Sinks | |
Design Resources | pushPIN™ Selector Tool | |
Featured Product | ATS - pushPIN™ Heat-sinks | |
Standard Package | 1 | |
Category | Fans, Thermal Management | |
Family | Thermal - Heat Sinks | |
Series | pushPIN™ | |
Type | Top Mount | |
Package Cooled | Assorted (BGA, LGA, CPU, ASIC...) | |
Attachment Method | Push Pin | |
Shape | Square, Fins | |
Length | 1.378" (35.00mm) | |
Width | 1.378" (35.00mm) | |
Diameter | - | |
Height Off Base (Height of Fin) | 0.590" (15.00mm) | |
Power Dissipation @ Temperature Rise | - | |
Thermal Resistance @ Forced Air Flow | 17.72°C/W @ 100 LFM | |
Thermal Resistance @ Natural | - | |
Material | Aluminum | |
Material Finish | Blue Anodized | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | ATS-09C-56-C2-R0 | |
Related Links | ATS-09C-, ATS-09C-56-C2-R0 Datasheet, Advanced Thermal Solutions Inc. Distributor |
