Atmel ATSAMS70Q20A-AN
- Mfg. Part Number
- ATSAMS70Q20A-AN
- Manufacturer
- Atmel
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT 1024KB FLASH
- Datasheet Download
- ATSAMS70Q20A-AN.pdf
Availability of ATSAMS70Q20A-AN
Available Quantity
5172 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.07500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ATSAMS70Q20A-AN, we specialize in Atmel all series electronic components. ATSAMS70Q20A-AN can be shipped within 24 hours after order. If you have any demands for ATSAMS70Q20A-AN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ATSAMS70Q20A-AN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ATSAMS70Q20A-AN
| Internal Part Number | EIS-ATSAMS70Q20A-AN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Introducing Atmel Studio 7 | |
| Design Resources | Development Tool Selector | |
| Standard Package | 60 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | SAM S70 | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M7 | |
| Core Size | 32-Bit | |
| Speed | 300MHz | |
| Connectivity | EBI/EMI, I²C, IrDA, LIN, MMC/SD/SDIO, SPI, UART/USART, USB | |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | |
| Number of I/O | 114 | |
| Program Memory Size | 1MB (1M x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 384K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.62 V ~ 3.6 V | |
| Data Converters | A/D 24x12b, D/A 2x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 144-LQFP | |
| Supplier Device Package | 144-LQFP (20x20) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATSAMS70Q20A-AN | |
| Related Links | ATSAMS7, ATSAMS70Q20A-AN Datasheet, Atmel Distributor | |
ATSAMS70Q20A-AN Details Description
