Atmel ATZB-RF-233-1-C
- Mfg. Part Number
- ATZB-RF-233-1-C
- Manufacturer
- Atmel
- Product Category
- RF Transceiver Modules
- Brief Description
- MODULE ZIGBIT AMP 2.4GHZ
- Datasheet Download
- ATZB-RF-233-1-C.pdf
Availability of ATZB-RF-233-1-C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 38.82800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ATZB-RF-233-1-C, we specialize in Atmel all series electronic components. ATZB-RF-233-1-C can be shipped within 24 hours after order. If you have any demands for ATZB-RF-233-1-C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ATZB-RF-233-1-C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ATZB-RF-233-1-C
| Internal Part Number | EIS-ATZB-RF-233-1-C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Introduction to IEEE 802.15.4 Low Power Wireless Networks | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver Modules | |
| Series | ZigBit™ | |
| Packaging | Tray | |
| RF Family/Standard | 802.15.4 | |
| Protocol | Zigbee® | |
| Modulation | - | |
| Frequency | 2.4GHz | |
| Data Rate | 2Mbps | |
| Power - Output | 19.9dBm | |
| Sensitivity | -105dBm | |
| Serial Interfaces | I²C, SPI, UART | |
| Antenna Type | Integrated, Chip | |
| Memory Size | - | |
| Voltage - Supply | 2 V ~ 3.6 V | |
| Current - Receiving | 17mA | |
| Current - Transmitting | 157mA | |
| Mounting Type | Surface Mount | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | Module | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ATZB-RF-233-1-C | |
| Related Links | ATZB-RF, ATZB-RF-233-1-C Datasheet, Atmel Distributor | |
ATZB-RF-233-1-C Details Description
