Panasonic Electric Works AXN480C030S
- Mfg. Part Number
- AXN480C030S
- Manufacturer
- Panasonic Electric Works
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN HEADER .8MM 80POS SMD
- Datasheet Download
- AXN480C030S.pdf
Availability of AXN480C030S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.58083
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of AXN480C030S, we specialize in Panasonic Electric Works all series electronic components. AXN480C030S can be shipped within 24 hours after order. If you have any demands for AXN480C030S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- AXN480C030S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
AXN480C030S
| Internal Part Number | EIS-AXN480C030S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Connectors SMD-Technical Info How to Read Date Codes | |
| Featured Product | Tough Contact Connector Series Hot New Technologies | |
| PCN Obsolescence/ EOL | P8 Series 17/Jan/2014 | |
| Standard Package | 12 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | P8 | |
| Packaging | Tube | |
| Connector Type | Header, Outer Shroud Contacts | |
| Number of Positions | 80 | |
| Pitch | 0.031" (0.80mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Mated Stacking Heights | 13mm | |
| Height Above Board | 0.399" (10.14mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | AXN480C030S | |
| Related Links | AXN48, AXN480C030S Datasheet, Panasonic Electric Works Distributor | |
