EPCOS (TDK) B82720H15A25
- Mfg. Part Number
- B82720H15A25
- Manufacturer
- EPCOS (TDK)
- Product Category
- Common Mode Chokes
- Brief Description
- DATA LINE CHOKE 2X10MH 0.6A
- Datasheet Download
- B82720H15A25.pdf
Availability of B82720H15A25
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.42867
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of B82720H15A25, we specialize in EPCOS (TDK) all series electronic components. B82720H15A25 can be shipped within 24 hours after order. If you have any demands for B82720H15A25, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- B82720H15A25 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
B82720H15A25
| Internal Part Number | EIS-B82720H15A25 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 450 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | B8272 | |
| Packaging | Tray | |
| Filter Type | Data, Signal Line | |
| Number of Lines | 2 | |
| Inductance | 10mH | |
| Current | 600mA | |
| DC Resistance (DCR) | 700 mOhm | |
| Impedance | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 0.512" L x 0.374" W (13.00mm x 9.50mm) | |
| Height (Max) | 0.551" (14.00mm) | |
| Package / Case | Vertical, 4 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | B82720H15A25 | |
| Related Links | B82720, B82720H15A25 Datasheet, EPCOS (TDK) Distributor | |
B82720H15A25 Details Description
