Micro Commercial Components (MCC) BAS70-04-TP
- Mfg. Part Number
- BAS70-04-TP
- Manufacturer
- Micro Commercial Components (MCC)
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 70V SOT23
- Datasheet Download
- BAS70-04-TP.pdf
Availability of BAS70-04-TP
Available Quantity
83020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.02340
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BAS70-04-TP, we specialize in Micro Commercial Components (MCC) all series electronic components. BAS70-04-TP can be shipped within 24 hours after order. If you have any demands for BAS70-04-TP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BAS70-04-TP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BAS70-04-TP
| Internal Part Number | EIS-BAS70-04-TP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Diode Handling and Mounting | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Configuration | 1 Pair Series Connection | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 70V | |
| Current - Average Rectified (Io) (per Diode) | 70mA (DC) | |
| Voltage - Forward (Vf) (Max) @ If | 1V @ 15mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | 5ns | |
| Current - Reverse Leakage @ Vr | 200nA @ 50V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BAS70-04-TP | |
| Related Links | BAS70, BAS70-04-TP Datasheet, Micro Commercial Components (MCC) Distributor | |
BAS70-04-TP Details Description
