ON Semiconductor BC848CDXV6T5G
- Mfg. Part Number
- BC848CDXV6T5G
- Manufacturer
- ON Semiconductor
- Product Category
- Transistors (BJT) - Arrays
- Brief Description
- TRANS 2NPN 30V 0.1A SOT563
- Datasheet Download
- BC848CDXV6T5G.pdf
Availability of BC848CDXV6T5G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BC848CDXV6T5G, we specialize in ON Semiconductor all series electronic components. BC848CDXV6T5G can be shipped within 24 hours after order. If you have any demands for BC848CDXV6T5G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BC848CDXV6T5G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BC848CDXV6T5G
| Internal Part Number | EIS-BC848CDXV6T5G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 8,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Arrays | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Transistor Type | 2 NPN (Dual) | |
| Current - Collector (Ic) (Max) | 100mA | |
| Voltage - Collector Emitter Breakdown (Max) | 30V | |
| Vce Saturation (Max) @ Ib, Ic | 600mV @ 5mA, 100mA | |
| Current - Collector Cutoff (Max) | 15nA (ICBO) | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 420 @ 2mA, 5V | |
| Power - Max | 500mW | |
| Frequency - Transition | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-563, SOT-666 | |
| Supplier Device Package | SOT-563 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BC848CDXV6T5G | |
| Related Links | BC848C, BC848CDXV6T5G Datasheet, ON Semiconductor Distributor | |
BC848CDXV6T5G Details Description
