Rohm Semiconductor BD2202G-LBTR
- Mfg. Part Number
- BD2202G-LBTR
- Manufacturer
- Rohm Semiconductor
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC LOAD SWITCH PORTABLE 5SSOP
- Datasheet Download
- BD2202G-LBTR.pdf
Availability of BD2202G-LBTR
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.55800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BD2202G-LBTR, we specialize in Rohm Semiconductor all series electronic components. BD2202G-LBTR can be shipped within 24 hours after order. If you have any demands for BD2202G-LBTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BD2202G-LBTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BD2202G-LBTR
| Internal Part Number | EIS-BD2202G-LBTR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 2.7 V ~ 3.6 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 200mA | |
| Rds On (Typ) | 150 mOhm | |
| Input Type | Non-Inverting | |
| Features | - | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO | |
| Operating Temperature | -25°C ~ 85°C (TA) | |
| Package / Case | SC-74A, SOT-753 | |
| Supplier Device Package | 5-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BD2202G-LBTR | |
| Related Links | BD2202, BD2202G-LBTR Datasheet, Rohm Semiconductor Distributor | |
BD2202G-LBTR Details Description
