Infineon Technologies BTS428L2
.jpg)
- Mfg. Part Number
- BTS428L2
- Manufacturer
- Infineon Technologies
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- SWITCH HIGH SIDE POWER TO252-5
- Datasheet Download
- BTS428L2.pdf
Availability of BTS428L2
Available Quantity
21115 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.48613
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BTS428L2, we specialize in Infineon Technologies all series electronic components. BTS428L2 can be shipped within 24 hours after order. If you have any demands for BTS428L2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BTS428L2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BTS428L2
| Internal Part Number | EIS-BTS428L2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Wafer Production Site 04/Dec/2013 | |
| PCN Packaging | Cover Tape Width Update 17/Jun/2015 Cover Tape Width Cancellation 14/Jul/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | PROFET® | |
| Packaging | Cut Tape (CT) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 4.75 V ~ 41 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 5.8A | |
| Rds On (Typ) | 50 mOhm | |
| Input Type | Non-Inverting | |
| Features | Status Flag | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD | |
| Supplier Device Package | P-TO252-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BTS428L2 | |
| Related Links | BTS4, BTS428L2 Datasheet, Infineon Technologies Distributor | |
BTS428L2 Details Description
