ON Semiconductor BZX84C4V7LT1
- Mfg. Part Number
- BZX84C4V7LT1
- Manufacturer
- ON Semiconductor
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 4.7V 225MW SOT23-3
- Datasheet Download
- BZX84C4V7LT1.pdf
Availability of BZX84C4V7LT1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of BZX84C4V7LT1, we specialize in ON Semiconductor all series electronic components. BZX84C4V7LT1 can be shipped within 24 hours after order. If you have any demands for BZX84C4V7LT1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- BZX84C4V7LT1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
BZX84C4V7LT1
| Internal Part Number | EIS-BZX84C4V7LT1 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 19/Jun/2009 | |
| PCN Design/Specification | Glue Mount Process 11/July/2008 Copper Wire 08/Jun/2009 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 4.7V | |
| Tolerance | ±6% | |
| Power - Max | 225mW | |
| Impedance (Max) (Zzt) | 80 Ohm | |
| Current - Reverse Leakage @ Vr | 3µA @ 2V | |
| Voltage - Forward (Vf) (Max) @ If | 900mV @ 10mA | |
| Operating Temperature | - | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23-3 (TO-236) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | BZX84C4V7LT1 | |
| Related Links | BZX84C, BZX84C4V7LT1 Datasheet, ON Semiconductor Distributor | |
BZX84C4V7LT1 Details Description
