TDK Corporation C0603C0G1E101G
- Mfg. Part Number
- C0603C0G1E101G
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 100PF 25V C0G 0201
- Datasheet Download
- C0603C0G1E101G.pdf
Availability of C0603C0G1E101G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C0603C0G1E101G, we specialize in TDK Corporation all series electronic components. C0603C0G1E101G can be shipped within 24 hours after order. If you have any demands for C0603C0G1E101G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C0603C0G1E101G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C0603C0G1E101G
| Internal Part Number | EIS-C0603C0G1E101G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 15,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 100pF | |
| Tolerance | ±2% | |
| Voltage - Rated | 25V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0201 (0603 Metric) | |
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.013" (0.33mm) | |
| Lead Spacing | - | |
| Features | - | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C0603C0G1E101G | |
| Related Links | C0603C0, C0603C0G1E101G Datasheet, TDK Corporation Distributor | |
C0603C0G1E101G Details Description
