TDK Corporation C1005NP02A331J050BA
- Mfg. Part Number
- C1005NP02A331J050BA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 330PF 100V NP0 0402
- Datasheet Download
- C1005NP02A331J050BA.pdf
Availability of C1005NP02A331J050BA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.02200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C1005NP02A331J050BA, we specialize in TDK Corporation all series electronic components. C1005NP02A331J050BA can be shipped within 24 hours after order. If you have any demands for C1005NP02A331J050BA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C1005NP02A331J050BA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C1005NP02A331J050BA
| Internal Part Number | EIS-C1005NP02A331J050BA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 10,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 330pF | |
| Tolerance | ±5% | |
| Voltage - Rated | 100V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 150°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.022" (0.55mm) | |
| Lead Spacing | - | |
| Features | High Temperature | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C1005NP02A331J050BA | |
| Related Links | C1005NP02, C1005NP02A331J050BA Datasheet, TDK Corporation Distributor | |
C1005NP02A331J050BA Details Description
