TDK Corporation C4532C0G3F101K160KA
-18.jpg)
- Mfg. Part Number
- C4532C0G3F101K160KA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 100PF 3KV C0G 1812
- Datasheet Download
- C4532C0G3F101K160KA.pdf
Availability of C4532C0G3F101K160KA
Available Quantity
37020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.18375
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C4532C0G3F101K160KA, we specialize in TDK Corporation all series electronic components. C4532C0G3F101K160KA can be shipped within 24 hours after order. If you have any demands for C4532C0G3F101K160KA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C4532C0G3F101K160KA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C4532C0G3F101K160KA
| Internal Part Number | EIS-C4532C0G3F101K160KA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | SEAT, CCV, and TVCL Design Tools C Series High Voltage Capacitors Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| RoHS Information | RoHS Certificate-MLCC | |
| Featured Product | High Voltage MLCCs | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 100pF | |
| Tolerance | ±10% | |
| Voltage - Rated | 3000V (3kV) | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 1812 (4532 Metric) | |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.071" (1.80mm) | |
| Lead Spacing | - | |
| Features | High Voltage | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C4532C0G3F101K160KA | |
| Related Links | C4532C0G3, C4532C0G3F101K160KA Datasheet, TDK Corporation Distributor | |
