TDK Corporation C5750X7S3A223K160KA
-18.jpg)
- Mfg. Part Number
- C5750X7S3A223K160KA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 0.022UF 1KV X7S 2220
- Datasheet Download
- C5750X7S3A223K160KA.pdf
Availability of C5750X7S3A223K160KA
Available Quantity
6624 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.57500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C5750X7S3A223K160KA, we specialize in TDK Corporation all series electronic components. C5750X7S3A223K160KA can be shipped within 24 hours after order. If you have any demands for C5750X7S3A223K160KA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C5750X7S3A223K160KA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C5750X7S3A223K160KA
| Internal Part Number | EIS-C5750X7S3A223K160KA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | SEAT, CCV, and TVCL Design Tools C Series High Voltage Capacitors Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| RoHS Information | RoHS Certificate-MLCC | |
| Featured Product | High Voltage MLCCs | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | C | |
| Packaging | Cut Tape (CT) | |
| Capacitance | 0.022µF | |
| Tolerance | ±10% | |
| Voltage - Rated | 1000V (1kV) | |
| Temperature Coefficient | X7S | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | General Purpose | |
| Ratings | - | |
| Package / Case | 2220 (5750 Metric) | |
| Size / Dimension | 0.224" L x 0.197" W (5.70mm x 5.00mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.071" (1.80mm) | |
| Lead Spacing | - | |
| Features | High Voltage | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C5750X7S3A223K160KA | |
| Related Links | C5750X7S3, C5750X7S3A223K160KA Datasheet, TDK Corporation Distributor | |
