Silicon Labs C8051F812-GU
- Mfg. Part Number
- C8051F812-GU
- Manufacturer
- Silicon Labs
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 8KB FLASH 24QSOP
- Datasheet Download
- C8051F812-GU.pdf
Availability of C8051F812-GU
Available Quantity
5071 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.10444
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C8051F812-GU, we specialize in Silicon Labs all series electronic components. C8051F812-GU can be shipped within 24 hours after order. If you have any demands for C8051F812-GU, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C8051F812-GU Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C8051F812-GU
| Internal Part Number | EIS-C8051F812-GU | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Serial Communication Overview | |
| Design Resources | Development Tool Selector | |
| Featured Product | QuickSense™ Portfolio | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 56 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | C8051F81x | |
| Packaging | Tube | |
| Core Processor | 8051 | |
| Core Size | 8-Bit | |
| Speed | 25MHz | |
| Connectivity | SMBus (2-Wire/I²C), SPI, UART/USART | |
| Peripherals | Cap Sense, POR, PWM, Temp Sensor, WDT | |
| Number of I/O | 17 | |
| Program Memory Size | 8KB (8K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 512 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 3.6 V | |
| Data Converters | A/D 16x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 24-SSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 24-QSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C8051F812-GU | |
| Related Links | C8051F, C8051F812-GU Datasheet, Silicon Labs Distributor | |
C8051F812-GU Details Description
