Silicon Labs C8051F864-C-GSR
- Mfg. Part Number
- C8051F864-C-GSR
- Manufacturer
- Silicon Labs
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8051 4KB SOIC16
- Datasheet Download
- C8051F864-C-GSR.pdf
Availability of C8051F864-C-GSR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.66812
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of C8051F864-C-GSR, we specialize in Silicon Labs all series electronic components. C8051F864-C-GSR can be shipped within 24 hours after order. If you have any demands for C8051F864-C-GSR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- C8051F864-C-GSR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
C8051F864-C-GSR
| Internal Part Number | EIS-C8051F864-C-GSR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | PB-1402201 Errata 20/Feb/2014 | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | C8051F86x | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | 8051 | |
| Core Size | 8-Bit | |
| Speed | 25MHz | |
| Connectivity | I²C, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 13 | |
| Program Memory Size | 4KB (4K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 512 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.2 V ~ 3.6 V | |
| Data Converters | - | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | C8051F864-C-GSR | |
| Related Links | C8051F8, C8051F864-C-GSR Datasheet, Silicon Labs Distributor | |
C8051F864-C-GSR Details Description
