ITT Cannon, LLC CA3102E18-12SWB05
- Mfg. Part Number
- CA3102E18-12SWB05
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 6 POS BOX MNT W/SKTS
- Datasheet Download
- CA3102E18-12SWB05.pdf
Availability of CA3102E18-12SWB05
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 30.30060
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CA3102E18-12SWB05, we specialize in ITT Cannon, LLC all series electronic components. CA3102E18-12SWB05 can be shipped within 24 hours after order. If you have any demands for CA3102E18-12SWB05, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CA3102E18-12SWB05 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CA3102E18-12SWB05
| Internal Part Number | EIS-CA3102E18-12SWB05 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-5015, CA-B | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 6 | |
| Shell Size - Insert | 18-12 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Solder Cup | |
| Fastening Type | Reverse Bayonet Lock | |
| Orientation | W | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | 22A | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CA3102E18-12SWB05 | |
| Related Links | CA3102E1, CA3102E18-12SWB05 Datasheet, ITT Cannon, LLC Distributor | |
CA3102E18-12SWB05 Details Description
