ITT Cannon, LLC CA3102E36-10PYF80
- Mfg. Part Number
- CA3102E36-10PYF80
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 48POS BOX MNT W/PINS
- Datasheet Download
- CA3102E36-10PYF80.pdf
Availability of CA3102E36-10PYF80
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 103.38100
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CA3102E36-10PYF80, we specialize in ITT Cannon, LLC all series electronic components. CA3102E36-10PYF80 can be shipped within 24 hours after order. If you have any demands for CA3102E36-10PYF80, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CA3102E36-10PYF80 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CA3102E36-10PYF80
| Internal Part Number | EIS-CA3102E36-10PYF80 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-5015, CA | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Male Pins | |
| Number of Positions | 48 | |
| Shell Size - Insert | 36-10 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Crimp | |
| Fastening Type | Threaded | |
| Orientation | Y | |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | 22A | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CA3102E36-10PYF80 | |
| Related Links | CA3102E3, CA3102E36-10PYF80 Datasheet, ITT Cannon, LLC Distributor | |
