ON Semiconductor CAT6219-285TDGT3
- Mfg. Part Number
- CAT6219-285TDGT3
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 2.85V 0.5A TSOT23-5
- Datasheet Download
- CAT6219-285TDGT3.pdf
Availability of CAT6219-285TDGT3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CAT6219-285TDGT3, we specialize in ON Semiconductor all series electronic components. CAT6219-285TDGT3 can be shipped within 24 hours after order. If you have any demands for CAT6219-285TDGT3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CAT6219-285TDGT3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CAT6219-285TDGT3
| Internal Part Number | EIS-CAT6219-285TDGT3 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 27/Jun/2014 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 2.85V | |
| Current - Output | 500mA | |
| Voltage - Dropout (Typical) | 0.3V @ 500mA | |
| Number of Regulators | 1 | |
| Voltage - Input | Up to 5.5V | |
| Current - Limit (Min) | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 | |
| Supplier Device Package | TSOT-23-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CAT6219-285TDGT3 | |
| Related Links | CAT6219-, CAT6219-285TDGT3 Datasheet, ON Semiconductor Distributor | |
CAT6219-285TDGT3 Details Description
