Panasonic Electric Works CB1-D-24V
- Mfg. Part Number
- CB1-D-24V
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY AUTOMOTIVE SPDT 20A 24V
- Datasheet Download
- CB1-D-24V.pdf
Availability of CB1-D-24V
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CB1-D-24V, we specialize in Panasonic Electric Works all series electronic components. CB1-D-24V can be shipped within 24 hours after order. If you have any demands for CB1-D-24V, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CB1-D-24V Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CB1-D-24V
| Internal Part Number | EIS-CB1-D-24V | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | General Appl Guidelines How to Read Date Codes | |
| PCN Obsolescence/ EOL | CA,CM,CB,CV Relays Apr/2012 | |
| Standard Package | 50 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | CB | |
| Packaging | Bulk | |
| Relay Type | Automotive | |
| Coil Type | Non Latching | |
| Coil Current | 75mA | |
| Coil Voltage | 24VDC | |
| Contact Form | SPDT (1 Form C) | |
| Contact Rating (Current) | 20A | |
| Switching Voltage | 28VDC - Nom | |
| Turn On Voltage (Max) | 14 VDC | |
| Turn Off Voltage (Min) | 2.4 VDC | |
| Operate Time | 15ms | |
| Release Time | - | |
| Features | Diode, Sealed - Fully | |
| Mounting Type | Socketable | |
| Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) | |
| Contact Material | Silver Alloy, Cadmium Free | |
| Coil Power | 1.8 W | |
| Coil Resistance | 320 Ohms | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CB1-D-24V | |
| Related Links | CB1-, CB1-D-24V Datasheet, Panasonic Electric Works Distributor | |
