TDK-Lambda Americas, Inc. CC1R5-4812DF-E
- Mfg. Part Number
- CC1R5-4812DF-E
- Manufacturer
- TDK-Lambda Americas, Inc.
- Product Category
- DC DC Converters
- Brief Description
- CONV DC/DC 1.5W DU 48V +-12V PCB
- Datasheet Download
- CC1R5-4812DF-E.pdf
Availability of CC1R5-4812DF-E
Available Quantity
5181 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.24000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CC1R5-4812DF-E, we specialize in TDK-Lambda Americas, Inc. all series electronic components. CC1R5-4812DF-E can be shipped within 24 hours after order. If you have any demands for CC1R5-4812DF-E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CC1R5-4812DF-E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CC1R5-4812DF-E
| Internal Part Number | EIS-CC1R5-4812DF-E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Drawings | CC1R5 Series Dip Side CC1R5 Series Dip Bottom CC1R5 Series Dip Footprint | |
| Standard Package | 50 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | CC-E | |
| Packaging | Tray | |
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 36V | |
| Voltage - Input (Max) | 76V | |
| Voltage - Output 1 | 12 ~ 15 V | |
| Voltage - Output 2 | -12 ~ -15 V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 60mA, 60mA | |
| Power (Watts) - Manufacture Series | 1W | |
| Voltage - Isolation | 500V | |
| Features | - | |
| Mounting Type | Through Hole | |
| Package / Case | 7-DIP Module | |
| Size / Dimension | 0.65" L x 0.65" W x 0.34" H (16.5mm x 16.6mm x 8.5mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | - | |
| Power (Watts) - Max | 1.5W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CC1R5-4812DF-E | |
| Related Links | CC1R5-4, CC1R5-4812DF-E Datasheet, TDK-Lambda Americas, Inc. Distributor | |
CC1R5-4812DF-E Details Description
