Texas Instruments CC2540F128RHAT
- Mfg. Part Number
- CC2540F128RHAT
- Manufacturer
- Texas Instruments
- Product Category
- RF Transceiver ICs
- Brief Description
- IC SOC BLUETOOTH SMART 40VQFN
- Datasheet Download
- CC2540F128RHAT.pdf
Availability of CC2540F128RHAT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.81250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CC2540F128RHAT, we specialize in Texas Instruments all series electronic components. CC2540F128RHAT can be shipped within 24 hours after order. If you have any demands for CC2540F128RHAT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CC2540F128RHAT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CC2540F128RHAT
| Internal Part Number | EIS-CC2540F128RHAT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | What is Bluetooth | |
| Design Resources | Development Tool Selector | |
| Featured Product | CC2540 Bluetooth System-on-Chip | |
| PCN Design/Specification | Cu Wire QFN Packages 25/Apr/2013 | |
| PCN Packaging | Conversion to 7" Reel 24/Jan/2014 | |
| Manufacturer Product Page | CC2540F128RHAT Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver ICs | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | TxRx + MCU | |
| RF Family/Standard | Bluetooth | |
| Protocol | Bluetooth v4.0 Low Energy | |
| Modulation | - | |
| Frequency | 2.4GHz | |
| Data Rate (Max) | 1Mbps | |
| Power - Output | 4dBm | |
| Sensitivity | -93dBm | |
| Memory Size | 128kB Flash, 8kB SRAM | |
| Serial Interfaces | SPI, UART | |
| GPIO | 21 | |
| Voltage - Supply | 2 V ~ 3.6 V | |
| Current - Receiving | 22.1mA | |
| Current - Transmitting | 31.6mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 40-VFQFN Exposed Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CC2540F128RHAT | |
| Related Links | CC2540F, CC2540F128RHAT Datasheet, Texas Instruments Distributor | |
