Texas Instruments CC2541F256TRHARQ1
- Mfg. Part Number
- CC2541F256TRHARQ1
- Manufacturer
- Texas Instruments
- Product Category
- RF Transceiver ICs
- Brief Description
- IC SOC BLUETOOTH SMART 40VQFN
- Datasheet Download
- CC2541F256TRHARQ1.pdf
Availability of CC2541F256TRHARQ1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.70700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CC2541F256TRHARQ1, we specialize in Texas Instruments all series electronic components. CC2541F256TRHARQ1 can be shipped within 24 hours after order. If you have any demands for CC2541F256TRHARQ1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CC2541F256TRHARQ1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CC2541F256TRHARQ1
| Internal Part Number | EIS-CC2541F256TRHARQ1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 2,500 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver ICs | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | TxRx + MCU | |
| RF Family/Standard | Bluetooth | |
| Protocol | Bluetooth v4.0 Low Energy | |
| Modulation | - | |
| Frequency | 2.4GHz | |
| Data Rate (Max) | 2Mbps | |
| Power - Output | 0dBm | |
| Sensitivity | -94dBm | |
| Memory Size | 256kB Flash, 8kB RAM | |
| Serial Interfaces | I²C, SPI, UART | |
| GPIO | 23 | |
| Voltage - Supply | 2 V ~ 3.6 V | |
| Current - Receiving | 17.9mA | |
| Current - Transmitting | 18.2mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 40-VFQFN Exposed Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CC2541F256TRHARQ1 | |
| Related Links | CC2541F2, CC2541F256TRHARQ1 Datasheet, Texas Instruments Distributor | |
CC2541F256TRHARQ1 Details Description
