Laird Technologies - Signal Integrity Products CC2824J502R-10
- Mfg. Part Number
- CC2824J502R-10
- Manufacturer
- Laird Technologies - Signal Integrity Products
- Product Category
- Common Mode Chokes
- Brief Description
- CHOKE CAN-BUS 5.0UH 1200MA
- Datasheet Download
- CC2824J502R-10.pdf
Availability of CC2824J502R-10
Available Quantity
6520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.60547
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CC2824J502R-10, we specialize in Laird Technologies - Signal Integrity Products all series electronic components. CC2824J502R-10 can be shipped within 24 hours after order. If you have any demands for CC2824J502R-10, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CC2824J502R-10 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CC2824J502R-10
| Internal Part Number | EIS-CC2824J502R-10 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,500 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | CC | |
| Packaging | Tape & Reel (TR) | |
| Filter Type | Data, Signal Line | |
| Number of Lines | 2 | |
| Inductance | 5µH | |
| Current | 1.2A | |
| DC Resistance (DCR) | 100 mOhm | |
| Impedance | 400 Ohm | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.354" L x 0.217" W (9.00mm x 5.50mm) | |
| Height (Max) | 0.193" (4.90mm) | |
| Package / Case | Horizontal, 4 Flat Lead | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CC2824J502R-10 | |
| Related Links | CC2824J, CC2824J502R-10 Datasheet, Laird Technologies - Signal Integrity Products Distributor | |
