Bourns Inc. CD214B-T18ALF
- Mfg. Part Number
- CD214B-T18ALF
- Manufacturer
- Bourns Inc.
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 18VWM 29.2VC DO214AA
- Datasheet Download
- CD214B-T18ALF.pdf
Availability of CD214B-T18ALF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.12150
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CD214B-T18ALF, we specialize in Bourns Inc. all series electronic components. CD214B-T18ALF can be shipped within 24 hours after order. If you have any demands for CD214B-T18ALF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CD214B-T18ALF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CD214B-T18ALF
| Internal Part Number | EIS-CD214B-T18ALF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 18V | |
| Voltage - Breakdown (Min) | 20V | |
| Voltage - Clamping (Max) @ Ipp | 29.2V | |
| Current - Peak Pulse (10/1000µs) | 20.5A | |
| Power - Peak Pulse | 600W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AA, SMB | |
| Supplier Device Package | SMB (DO-214AA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CD214B-T18ALF | |
| Related Links | CD214B, CD214B-T18ALF Datasheet, Bourns Inc. Distributor | |
CD214B-T18ALF Details Description
