Microsemi Commercial Components CDLL0.2A30
- Mfg. Part Number
- CDLL0.2A30
- Manufacturer
- Microsemi Commercial Components
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 30V 200MA DO213AA
- Datasheet Download
- CDLL0.2A30.pdf
Availability of CDLL0.2A30
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.33000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CDLL0.2A30, we specialize in Microsemi Commercial Components all series electronic components. CDLL0.2A30 can be shipped within 24 hours after order. If you have any demands for CDLL0.2A30, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CDLL0.2A30 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CDLL0.2A30
| Internal Part Number | EIS-CDLL0.2A30 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Bulk | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 30V | |
| Current - Average Rectified (Io) | 200mA | |
| Voltage - Forward (Vf) (Max) @ If | 500mV @ 200mA | |
| Speed | Small Signal =< 200mA (Io), Any Speed | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 5µA @ 30V | |
| Capacitance @ Vr, F | 50pF @ 0V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-213AA | |
| Supplier Device Package | DO-213AA | |
| Operating Temperature - Junction | -65°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CDLL0.2A30 | |
| Related Links | CDLL0, CDLL0.2A30 Datasheet, Microsemi Commercial Components Distributor | |
CDLL0.2A30 Details Description
