TDK Corporation CGA3E2NP02A180J080AA
- Mfg. Part Number
- CGA3E2NP02A180J080AA
- Manufacturer
- TDK Corporation
- Product Category
- Ceramic Capacitors
- Brief Description
- CAP CER 18PF 100V NP0 0603
- Datasheet Download
- CGA3E2NP02A180J080AA.pdf
Availability of CGA3E2NP02A180J080AA
Available Quantity
17020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.01649
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CGA3E2NP02A180J080AA, we specialize in TDK Corporation all series electronic components. CGA3E2NP02A180J080AA can be shipped within 24 hours after order. If you have any demands for CGA3E2NP02A180J080AA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CGA3E2NP02A180J080AA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CGA3E2NP02A180J080AA
| Internal Part Number | EIS-CGA3E2NP02A180J080AA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | CGA Series for Automotive Applications SEAT, CCV, and TVCL Design Tools Guide to Replacing an Electrolytic Capacitor with an MLCC | |
| Video File | High Capacitance Capacitor Measurement Tutorial | |
| RoHS Information | RoHS Certificate-MLCC | |
| Featured Product | CGA Series MLCC Capacitors | |
| PCN Part Number | MLCC Part Number Change 30/Nov/2012 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 4,000 | |
| Category | Capacitors | |
| Family | Ceramic Capacitors | |
| Series | CGA | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 18pF | |
| Tolerance | ±5% | |
| Voltage - Rated | 100V | |
| Temperature Coefficient | C0G, NP0 | |
| Mounting Type | Surface Mount, MLCC | |
| Operating Temperature | -55°C ~ 150°C | |
| Applications | Automotive | |
| Ratings | AEC-Q200 | |
| Package / Case | 0603 (1608 Metric) | |
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) | |
| Height - Seated (Max) | - | |
| Thickness (Max) | 0.035" (0.90mm) | |
| Lead Spacing | - | |
| Features | High Temperature | |
| Lead Style | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CGA3E2NP02A180J080AA | |
| Related Links | CGA3E2NP02, CGA3E2NP02A180J080AA Datasheet, TDK Corporation Distributor | |
