NKK Switches CKL12ATW01-034
- Mfg. Part Number
- CKL12ATW01-034
- Manufacturer
- NKK Switches
- Product Category
- Keylock Switches
- Brief Description
- SWITCH KEYLOCK 19MM KEYCODE 034
- Datasheet Download
- CKL12ATW01-034.pdf
Availability of CKL12ATW01-034
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.46000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CKL12ATW01-034, we specialize in NKK Switches all series electronic components. CKL12ATW01-034 can be shipped within 24 hours after order. If you have any demands for CKL12ATW01-034, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CKL12ATW01-034 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CKL12ATW01-034
| Internal Part Number | EIS-CKL12ATW01-034 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics 3D CAD Models | |
| RoHS Information | Series, Cert of Compliance | |
| 3D Model | CKL12ATW01 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Keylock Switches | |
| Series | CK | |
| Circuit | SPDT | |
| Number of Positions | 2 | |
| Switch Function | On-On | |
| Contact Timing | Non-Shorting (BBM) | |
| Current Rating | 3A (AC) | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | - | |
| Actuator Type | Tubular Key | |
| Key Removable Positions | All | |
| Angle of Throw | 90° | |
| Contact Material | Silver (Ag) | |
| Contact Finish | Silver | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Panel Cutout Dimensions | Circular - 19.00mm Dia | |
| Features | Epoxy Sealed Terminals | |
| Depth Behind Flange | 34.60mm | |
| Operating Temperature | -25°C ~ 70°C | |
| Mechanical Life | 30,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CKL12ATW01-034 | |
| Related Links | CKL12AT, CKL12ATW01-034 Datasheet, NKK Switches Distributor | |
CKL12ATW01-034 Details Description
