API Delevan CM6149R-334
- Mfg. Part Number
- CM6149R-334
- Manufacturer
- API Delevan
- Product Category
- Common Mode Chokes
- Brief Description
- CHOKE LOW PROFILE 330 UH 25% SMD
- Datasheet Download
- CM6149R-334.pdf
Availability of CM6149R-334
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.55350
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CM6149R-334, we specialize in API Delevan all series electronic components. CM6149R-334 can be shipped within 24 hours after order. If you have any demands for CM6149R-334, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CM6149R-334 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CM6149R-334
| Internal Part Number | EIS-CM6149R-334 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 800 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | CM6149R | |
| Packaging | Tape & Reel (TR) | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 330µH | |
| Current | 750mA | |
| DC Resistance (DCR) | 90 mOhm Max | |
| Impedance | - | |
| Operating Temperature | -55°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.285" L x 0.285" W (7.24mm x 7.24mm) | |
| Height (Max) | 0.210" (5.33mm) | |
| Package / Case | Horizontal, 4 PC Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CM6149R-334 | |
| Related Links | CM614, CM6149R-334 Datasheet, API Delevan Distributor | |
CM6149R-334 Details Description
