API Delevan CMT4545R-112M
- Mfg. Part Number
- CMT4545R-112M
- Manufacturer
- API Delevan
- Product Category
- Arrays, Signal Transformers
- Brief Description
- INDUCT ARRAY 2 COIL 10UH SMD
- Datasheet Download
- CMT4545R-112M.pdf
Availability of CMT4545R-112M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 27.55760
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CMT4545R-112M, we specialize in API Delevan all series electronic components. CMT4545R-112M can be shipped within 24 hours after order. If you have any demands for CMT4545R-112M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CMT4545R-112M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CMT4545R-112M
| Internal Part Number | EIS-CMT4545R-112M | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Inductors, Coils, Chokes | |
| Family | Arrays, Signal Transformers | |
| Series | CMT4545R | |
| Packaging | Tape & Reel (TR) | |
| Number of Coils | 2 | |
| Inductance - Connected In Series | 42.4µH | |
| Inductance - Connected In Parallel | 10µH | |
| Tolerance | ±20% | |
| Current Rating - Parallel | 3.9A | |
| Current Rating - Series | 2A | |
| Current Saturation - Parallel | - | |
| Current Saturation - Series | - | |
| DC Resistance (DCR) - Parallel | 20 mOhm | |
| DC Resistance (DCR) - Series | 80 mOhm | |
| Shielding | Unshielded | |
| Operating Temperature | - | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.450" L x 0.450" W (11.43mm x 11.43mm) | |
| Height | 0.250" (6.35mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CMT4545R-112M | |
| Related Links | CMT454, CMT4545R-112M Datasheet, API Delevan Distributor | |
CMT4545R-112M Details Description
