Linx Technologies CONSMA011-R58
- Mfg. Part Number
- CONSMA011-R58
- Manufacturer
- Linx Technologies
- Product Category
- Coaxial Connectors (RF)
- Brief Description
- CONN SMA JACK STR 50 OHM SOLDER
- Datasheet Download
- CONSMA011-R58.pdf
Availability of CONSMA011-R58
Available Quantity
5245 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.01250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CONSMA011-R58, we specialize in Linx Technologies all series electronic components. CONSMA011-R58 can be shipped within 24 hours after order. If you have any demands for CONSMA011-R58, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CONSMA011-R58 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CONSMA011-R58
| Internal Part Number | EIS-CONSMA011-R58 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | FCC and Legal Considerations with Linx Radio Modules Introduction to the RF Environment | |
| RoHS Information | RoHS Cert of Compliance | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) | |
| Series | - | |
| Packaging | Bulk | |
| Connector Style | SMA | |
| Connector Type | Jack, Female Socket | |
| Contact Termination | Solder | |
| Shield Termination | Crimp | |
| Impedance | 50 Ohm | |
| Mounting Type | Free Hanging (In-Line) | |
| Cable Group | RG-58 | |
| Fastening Type | Threaded | |
| Frequency - Max | 12.4GHz | |
| Features | Heat Shrink Tubing | |
| Housing Color | Silver | |
| Ingress Protection | - | |
| Body Material | Brass | |
| Body Finish | Nickel | |
| Center Contact Material | Beryllium Copper | |
| Center Contact Plating | Gold | |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | |
| Voltage Rating | - | |
| Operating Temperature | -65°C ~ 165°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CONSMA011-R58 | |
| Related Links | CONSMA, CONSMA011-R58 Datasheet, Linx Technologies Distributor | |
