Vishay Semiconductor/Diodes Division CPV364M4F
- Mfg. Part Number
- CPV364M4F
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- IGBTs - Modules
- Brief Description
- IGBT SIP MODULE 600V 15A IMS-2
- Datasheet Download
- CPV364M4F.pdf
Availability of CPV364M4F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CPV364M4F, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. CPV364M4F can be shipped within 24 hours after order. If you have any demands for CPV364M4F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CPV364M4F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CPV364M4F
| Internal Part Number | EIS-CPV364M4F | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 84 | |
| Category | Discrete Semiconductor Products | |
| Family | IGBTs - Modules | |
| Series | - | |
| IGBT Type | - | |
| Configuration | Three Phase Inverter | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 27A | |
| Power - Max | 63W | |
| Vce(on) (Max) @ Vge, Ic | 1.6V @ 15V, 27A | |
| Current - Collector Cutoff (Max) | 250µA | |
| Input Capacitance (Cies) @ Vce | 2.2nF @ 30V | |
| Input | Standard | |
| NTC Thermistor | No | |
| Mounting Type | Through Hole | |
| Package / Case | 19-SIP (13 Leads), IMS-2 | |
| Supplier Device Package | IMS-2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CPV364M4F | |
| Related Links | CPV3, CPV364M4F Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
