Standex-Meder Electronics CRR05-1AS
- Mfg. Part Number
- CRR05-1AS
- Manufacturer
- Standex-Meder Electronics
- Product Category
- Signal Relays, Up to 2 Amps
- Brief Description
- RELAY REED SPST 500MA 5V
- Datasheet Download
- CRR05-1AS.pdf
Availability of CRR05-1AS
Available Quantity
6020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.53700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CRR05-1AS, we specialize in Standex-Meder Electronics all series electronic components. CRR05-1AS can be shipped within 24 hours after order. If you have any demands for CRR05-1AS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CRR05-1AS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CRR05-1AS
| Internal Part Number | EIS-CRR05-1AS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Magnetic Mapping RF Reed Relays Presentation – Part 1 RF Reed Relays Presentation-Part 2 | |
| Standard Package | 1,000 | |
| Category | Relays | |
| Family | Signal Relays, Up to 2 Amps | |
| Series | CRR | |
| Packaging | Tape & Reel (TR) | |
| Relay Type | Reed | |
| Coil Type | Non Latching | |
| Coil Current | 33.3mA | |
| Coil Voltage | 5VDC | |
| Contact Form | SPST-NO (1 Form A) | |
| Contact Rating (Current) | 500mA | |
| Switching Voltage | 170VAC, 170VDC - Max | |
| Turn On Voltage (Max) | 3.75 VDC | |
| Turn Off Voltage (Min) | 0.75 VDC | |
| Operate Time | 0.1ms | |
| Release Time | 0.02ms | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Termination Style | BGA | |
| Contact Material | - | |
| Coil Power | 167 mW | |
| Coil Resistance | 150 Ohms | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CRR05-1AS | |
| Related Links | CRR0, CRR05-1AS Datasheet, Standex-Meder Electronics Distributor | |
CRR05-1AS Details Description
