Cirrus Logic, Inc. CS1615-FSZ
- Mfg. Part Number
- CS1615-FSZ
- Manufacturer
- Cirrus Logic, Inc.
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver AC DC Offline Switcher Triac Dimming Lighting 16-SOIC N
- Datasheet Download
- CS1615-FSZ.pdf
Availability of CS1615-FSZ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.34060
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CS1615-FSZ, we specialize in Cirrus Logic, Inc. all series electronic components. CS1615-FSZ can be shipped within 24 hours after order. If you have any demands for CS1615-FSZ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CS1615-FSZ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CS1615-FSZ
| Internal Part Number | EIS-CS1615-FSZ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Reference Design Library | CRD1615-8W-Z: 10 LEDs @ 250mA, 108 ~ 132 VAC in | |
| PCN Obsolescence/ EOL | CS1615/16 Devices 28/Jul/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 48 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Bulk | |
| Type | AC DC Offline Switcher | |
| Topology | Flyback, Step-Down (Buck), Step-Up (Boost) | |
| Internal Switch(s) | No | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | 11V | |
| Voltage - Supply (Max) | 17V | |
| Voltage - Output | - | |
| Current - Output / Channel | - | |
| Frequency | 6kHz ~ 200kHz | |
| Dimming | Triac | |
| Applications | Lighting | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-SOIC N | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CS1615-FSZ | |
| Related Links | CS161, CS1615-FSZ Datasheet, Cirrus Logic, Inc. Distributor | |
