Cirrus Logic, Inc. CS47024C-CQZR
- Mfg. Part Number
- CS47024C-CQZR
- Manufacturer
- Cirrus Logic, Inc.
- Product Category
- Embedded - DSP (Digital Signal Processors)
- Brief Description
- IC AUDIO SOC SGL 32BIT 100LQFP
- Datasheet Download
- CS47024C-CQZR.pdf
Availability of CS47024C-CQZR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 14.72460
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CS47024C-CQZR, we specialize in Cirrus Logic, Inc. all series electronic components. CS47024C-CQZR can be shipped within 24 hours after order. If you have any demands for CS47024C-CQZR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CS47024C-CQZR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CS47024C-CQZR
| Internal Part Number | EIS-CS47024C-CQZR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | CS470xx Firmware User Manual | |
| PCN Design/Specification | Laser Marking Update 07/May/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - DSP (Digital Signal Processors) | |
| Series | CS470xx | |
| Packaging | Tape & Reel (TR) | |
| Type | Fixed Point | |
| Interface | I²C, SPI | |
| Clock Rate | 150MHz | |
| Non-Volatile Memory | - | |
| On-Chip RAM | 128kB | |
| Voltage - I/O | 3.30V | |
| Voltage - Core | 1.80V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 100-LQFP Exposed Pad | |
| Supplier Device Package | 100-LQFP (16x16) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CS47024C-CQZR | |
| Related Links | CS4702, CS47024C-CQZR Datasheet, Cirrus Logic, Inc. Distributor | |
CS47024C-CQZR Details Description
