ON Semiconductor CS8126-1YTHE5
- Mfg. Part Number
- CS8126-1YTHE5
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 5V 0.5A TO220-5
- Datasheet Download
- CS8126-1YTHE5.pdf
Availability of CS8126-1YTHE5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CS8126-1YTHE5, we specialize in ON Semiconductor all series electronic components. CS8126-1YTHE5 can be shipped within 24 hours after order. If you have any demands for CS8126-1YTHE5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CS8126-1YTHE5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CS8126-1YTHE5
| Internal Part Number | EIS-CS8126-1YTHE5 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Apr/2007 | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tube | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 5V | |
| Current - Output | 500mA | |
| Voltage - Dropout (Typical) | 0.35V @ 500mA | |
| Number of Regulators | 1 | |
| Voltage - Input | 6 V ~ 26 V | |
| Current - Limit (Min) | 750mA | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-5 Formed Leads | |
| Supplier Device Package | TO-220-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CS8126-1YTHE5 | |
| Related Links | CS8126, CS8126-1YTHE5 Datasheet, ON Semiconductor Distributor | |
CS8126-1YTHE5 Details Description
