Copal Electronics CSS-1312TB
- Mfg. Part Number
- CSS-1312TB
- Manufacturer
- Copal Electronics
- Product Category
- Slide Switches
- Brief Description
- SWITCH SLIDE SP3T 100MA 12V
- Datasheet Download
- CSS-1312TB.pdf
Availability of CSS-1312TB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.39270
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CSS-1312TB, we specialize in Copal Electronics all series electronic components. CSS-1312TB can be shipped within 24 hours after order. If you have any demands for CSS-1312TB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CSS-1312TB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CSS-1312TB
| Internal Part Number | EIS-CSS-1312TB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | CSS-1312TB | |
| Standard Package | 1,900 | |
| Category | Switches | |
| Family | Slide Switches | |
| Series | CSS | |
| Packaging | Tape & Reel (TR) | |
| Circuit | SP3T | |
| Contact Timing | Non-Shorting (BBM) | |
| Switch Function | Mom-On-Mom | |
| Current Rating | 100mA (DC) | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 12V | |
| Actuator Type | Standard | |
| Actuator Length | 2.00mm | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Mounting Type | Surface Mount, Right Angle | |
| Termination Style | Gull Wing | |
| Features | - | |
| Actuator Material | Liquid Crystal Polymer (LCP) | |
| Switch Travel | 2.00mm | |
| Operating Temperature | -20°C ~ 70°C | |
| Mechanical Life | - | |
| Electrical Life | 10,000 Cycles | |
| Operating Force | 102 ~ 357gf | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CSS-1312TB | |
| Related Links | CSS-1, CSS-1312TB Datasheet, Copal Electronics Distributor | |
CSS-1312TB Details Description
