Switchcraft Inc. CXC3102A2821S
- Mfg. Part Number
- CXC3102A2821S
- Manufacturer
- Switchcraft Inc.
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 37POS PNL MNT SKT
- Datasheet Download
- CXC3102A2821S.pdf
Availability of CXC3102A2821S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 50.93400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CXC3102A2821S, we specialize in Switchcraft Inc. all series electronic components. CXC3102A2821S can be shipped within 24 hours after order. If you have any demands for CXC3102A2821S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CXC3102A2821S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CXC3102A2821S
| Internal Part Number | EIS-CXC3102A2821S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-E-QUAL® | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 37 | |
| Shell Size - Insert | 28-21 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Crimp | |
| Fastening Type | Threaded | |
| Orientation | Keyed | |
| Ingress Protection | Weathertight | |
| Shell Material, Finish | Nylon | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | - | |
| Voltage - Rated | 500V | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CXC3102A2821S | |
| Related Links | CXC310, CXC3102A2821S Datasheet, Switchcraft Inc. Distributor | |
CXC3102A2821S Details Description
