Switchcraft Inc. CXS3106A2821S
- Mfg. Part Number
- CXS3106A2821S
- Manufacturer
- Switchcraft Inc.
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 37POS STRGHT SKT
- Datasheet Download
- CXS3106A2821S.pdf
Availability of CXS3106A2821S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 53.58600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CXS3106A2821S, we specialize in Switchcraft Inc. all series electronic components. CXS3106A2821S can be shipped within 24 hours after order. If you have any demands for CXS3106A2821S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CXS3106A2821S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CXS3106A2821S
| Internal Part Number | EIS-CXS3106A2821S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-E-QUAL® | |
| Packaging | Bulk | |
| Connector Type | Plug, Female Sockets | |
| Number of Positions | 37 | |
| Shell Size - Insert | 28-21 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Solder | |
| Fastening Type | Threaded | |
| Orientation | Keyed | |
| Ingress Protection | Weathertight | |
| Shell Material, Finish | Nylon | |
| Contact Finish | Silver | |
| Features | Cable Clamp | |
| Contact Finish Thickness | - | |
| Current Rating | - | |
| Voltage - Rated | 500V | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CXS3106A2821S | |
| Related Links | CXS310, CXS3106A2821S Datasheet, Switchcraft Inc. Distributor | |
