Cypress Semiconductor CY22395FXI
- Mfg. Part Number
- CY22395FXI
- Manufacturer
- Cypress Semiconductor
- Product Category
- Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
- Brief Description
- IC CLOCK GEN PROG 16-TSSOP
- Datasheet Download
- CY22395FXI.pdf
Availability of CY22395FXI
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY22395FXI, we specialize in Cypress Semiconductor all series electronic components. CY22395FXI can be shipped within 24 hours after order. If you have any demands for CY22395FXI, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY22395FXI Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY22395FXI
| Internal Part Number | EIS-CY22395FXI | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Copper Wire Bonds/Transfer 14/Jun/2013 GSMC Manufacture Merger 15/May/2014 Test/Finish Site Addition 19/Dec/2014 Assembly Site Add 17/Sep/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 96 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers | |
| Series | - | |
| Packaging | Tube | |
| Type | Clock Generator, Fanout Distribution | |
| PLL | Yes with Bypass | |
| Input | LVTTL, Crystal | |
| Output | CMOS, LVCMOS | |
| Number of Circuits | 1 | |
| Ratio - Input:Output | 1:5 | |
| Differential - Input:Output | No/No | |
| Frequency - Max | 133MHz, 166MHz | |
| Divider/Multiplier | Yes/No | |
| Voltage - Supply | 2.375 V ~ 3.465 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 16-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY22395FXI | |
| Related Links | CY223, CY22395FXI Datasheet, Cypress Semiconductor Distributor | |
CY22395FXI Details Description
