Cypress Semiconductor CY8C21223-24SXI
- Mfg. Part Number
- CY8C21223-24SXI
- Manufacturer
- Cypress Semiconductor
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 4K FLASH 256B SRAM 16SOIC
- Datasheet Download
- CY8C21223-24SXI.pdf
Availability of CY8C21223-24SXI
Available Quantity
5034 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.04400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of CY8C21223-24SXI, we specialize in Cypress Semiconductor all series electronic components. CY8C21223-24SXI can be shipped within 24 hours after order. If you have any demands for CY8C21223-24SXI, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- CY8C21223-24SXI Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
CY8C21223-24SXI
| Internal Part Number | EIS-CY8C21223-24SXI | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Featured Product | CapSense Sensing Technology | |
| PCN Assembly/Origin | Copper Wire Bonds/Transfer 14/Jun/2013 GSMC Manufacture Merger 15/May/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 48 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PSOC®1 CY8C21xxx | |
| Packaging | Tube | |
| Core Processor | M8C | |
| Core Size | 8-Bit | |
| Speed | 24MHz | |
| Connectivity | I²C, SPI, UART/USART | |
| Peripherals | POR, PWM, WDT | |
| Number of I/O | 12 | |
| Program Memory Size | 4KB (4K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 256 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.4 V ~ 5.25 V | |
| Data Converters | A/D 8x8b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | CY8C21223-24SXI | |
| Related Links | CY8C212, CY8C21223-24SXI Datasheet, Cypress Semiconductor Distributor | |
