3M D2564-6V0C-AR-WH
- Mfg. Part Number
- D2564-6V0C-AR-WH
- Manufacturer
- 3M
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 64POS SMD VERT 10AU
- Datasheet Download
- D2564-6V0C-AR-WH.pdf
Availability of D2564-6V0C-AR-WH
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.57000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D2564-6V0C-AR-WH, we specialize in 3M all series electronic components. D2564-6V0C-AR-WH can be shipped within 24 hours after order. If you have any demands for D2564-6V0C-AR-WH, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D2564-6V0C-AR-WH Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D2564-6V0C-AR-WH
| Internal Part Number | EIS-D2564-6V0C-AR-WH | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | IDC Wiremount Connectors Primer | |
| Standard Package | 200 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | D2500 | |
| Packaging | Tape & Reel (TR) | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 64 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Contact Mating Length | 0.243" (6.17mm) | |
| Mounting Type | Surface Mount | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D2564-6V0C-AR-WH | |
| Related Links | D2564-6V, D2564-6V0C-AR-WH Datasheet, 3M Distributor | |
D2564-6V0C-AR-WH Details Description
