Omron D2MQ-4L-1-R
- Mfg. Part Number
- D2MQ-4L-1-R
- Manufacturer
- Omron
- Product Category
- Snap Action, Limit Switches
- Brief Description
- BASIC SWITCH
- Datasheet Download
- D2MQ-4L-1-R.pdf
Availability of D2MQ-4L-1-R
Available Quantity
6015 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.07144
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D2MQ-4L-1-R, we specialize in Omron all series electronic components. D2MQ-4L-1-R can be shipped within 24 hours after order. If you have any demands for D2MQ-4L-1-R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D2MQ-4L-1-R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D2MQ-4L-1-R
| Internal Part Number | EIS-D2MQ-4L-1-R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Snap Switches | |
| Standard Package | 1,000 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | D2MQ | |
| Packaging | Tray | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 500mA (DC) | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Lever, Straight | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Ingress Protection | IP40 | |
| Features | - | |
| Operating Force, Torque | 40gf | |
| Release Force | 4gf | |
| Pretravel | 0.083" (2.1mm) | |
| Differential Travel | 0.027" (0.7mm) | |
| Overtravel | 0.011" (0.3mm) | |
| Operating Position | 0.280" (7.1mm) | |
| Mechanical Life | 30,000 Cycles | |
| Electrical Life | 10,000 Cycles | |
| Operating Temperature | -15°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D2MQ-4L-1-R | |
| Related Links | D2MQ-, D2MQ-4L-1-R Datasheet, Omron Distributor | |
D2MQ-4L-1-R Details Description
