Omron D2SW-P01L2T
- Mfg. Part Number
- D2SW-P01L2T
- Manufacturer
- Omron
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SW HING RLLR LEVER SPDT .1A 125V
- Datasheet Download
- D2SW-P01L2T.pdf
Availability of D2SW-P01L2T
Available Quantity
5483 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.77450
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D2SW-P01L2T, we specialize in Omron all series electronic components. D2SW-P01L2T can be shipped within 24 hours after order. If you have any demands for D2SW-P01L2T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D2SW-P01L2T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D2SW-P01L2T
| Internal Part Number | EIS-D2SW-P01L2T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Snap Switches | |
| Standard Package | 500 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | D2SW-P | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 100mA (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Lever, Roller | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | - | |
| Operating Force, Torque | 61gf | |
| Release Force | 5gf | |
| Pretravel | - | |
| Differential Travel | 0.031" (0.8mm) | |
| Overtravel | 0.030" (0.76mm) | |
| Operating Position | 0.571" (14.5mm) | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 200,000 Cycles | |
| Operating Temperature | -20°C ~ 70°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D2SW-P01L2T | |
| Related Links | D2SW-, D2SW-P01L2T Datasheet, Omron Distributor | |
D2SW-P01L2T Details Description
