Omron D2SW3M0
- Mfg. Part Number
- D2SW3M0
- Manufacturer
- Omron
- Product Category
- Snap Action, Limit Switches
- Brief Description
- MINIATURE BASIC SWITCH
- Datasheet Download
- D2SW3M0.pdf
Availability of D2SW3M0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 10.08800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D2SW3M0, we specialize in Omron all series electronic components. D2SW3M0 can be shipped within 24 hours after order. If you have any demands for D2SW3M0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D2SW3M0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D2SW3M0
| Internal Part Number | EIS-D2SW3M0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Snap Switches | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | D2SW | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 3A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Wire Leads | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Features | - | |
| Operating Force, Torque | 180gf | |
| Release Force | 30gf | |
| Pretravel | 0.024" (0.6mm) | |
| Differential Travel | 0.004" (0.1mm) | |
| Overtravel | 0.020" (0.5mm) | |
| Operating Position | 0.330" (8.4mm) | |
| Mechanical Life | 5,000,000 Cycles | |
| Electrical Life | 200,000 Cycles | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D2SW3M0 | |
| Related Links | D2S, D2SW3M0 Datasheet, Omron Distributor | |
