Omron D3V-6G5M-1C24
- Mfg. Part Number
- D3V-6G5M-1C24
- Manufacturer
- Omron
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH ROLLER SPDT 6A QC TERM
- Datasheet Download
- D3V-6G5M-1C24.pdf
Availability of D3V-6G5M-1C24
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.18470
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of D3V-6G5M-1C24, we specialize in Omron all series electronic components. D3V-6G5M-1C24 can be shipped within 24 hours after order. If you have any demands for D3V-6G5M-1C24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- D3V-6G5M-1C24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
D3V-6G5M-1C24
| Internal Part Number | EIS-D3V-6G5M-1C24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Product Training Modules | Snap Switches | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | D3V | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 6A (AC/DC) | |
| Voltage Rating - AC | 250V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Lever, Roller | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.187" (4.7mm) | |
| Ingress Protection | IP40 | |
| Features | - | |
| Operating Force, Torque | 120gf | |
| Release Force | 15gf | |
| Pretravel | 0.063" (1.6mm) | |
| Differential Travel | 0.020" (0.5mm) | |
| Overtravel | 0.031" (0.79mm) | |
| Operating Position | 0.815" (20.7mm) | |
| Mechanical Life | 10,000,000 Cycles | |
| Electrical Life | 500,000 Cycles | |
| Operating Temperature | -25°C ~ 105°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | D3V-6G5M-1C24 | |
| Related Links | D3V-6G, D3V-6G5M-1C24 Datasheet, Omron Distributor | |
