ITT Cannon, LLC DAMM15PMA159
- Mfg. Part Number
- DAMM15PMA159
- Manufacturer
- ITT Cannon, LLC
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Plug, Male Pins 15 Position Panel Mount, Through Hole Solder
- Datasheet Download
- DAMM15PMA159.pdf
Availability of DAMM15PMA159
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.06640
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DAMM15PMA159, we specialize in ITT Cannon, LLC all series electronic components. DAMM15PMA159 can be shipped within 24 hours after order. If you have any demands for DAMM15PMA159, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DAMM15PMA159 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DAMM15PMA159
| Internal Part Number | EIS-DAMM15PMA159 | |
| Lead Free Status / RoHS Status | Vendor undefined / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | MIL-DTL-24308, D*MM | |
| Packaging | Bulk | |
| Connector Style | D-Sub | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 15 | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 2 (DA, A) | |
| Contact Type | Signal | |
| Mounting Type | Panel Mount, Through Hole | |
| Flange Feature | Housing/Shell (Unthreaded) | |
| Termination | Solder | |
| Features | - | |
| Shell Material, Finish | Steel, Nickel Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 150°C | |
| Voltage Rating | - | |
| Current Rating | 7.5A | |
| Housing Material | Polyester | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DAMM15PMA159 | |
| Related Links | DAMM15, DAMM15PMA159 Datasheet, ITT Cannon, LLC Distributor | |
DAMM15PMA159 Details Description
