FFF DBL5W5P500H30LF
- Mfg. Part Number
- DBL5W5P500H30LF
- Manufacturer
- FFF
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Plug, Male Pins 5 (Power) Position Through Hole, Right Angle Solder
- Datasheet Download
- DBL5W5P500H30LF.pdf
Availability of DBL5W5P500H30LF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 15.90331
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DBL5W5P500H30LF, we specialize in FFF all series electronic components. DBL5W5P500H30LF can be shipped within 24 hours after order. If you have any demands for DBL5W5P500H30LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DBL5W5P500H30LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DBL5W5P500H30LF
| Internal Part Number | EIS-DBL5W5P500H30LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 20 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | DW | |
| Packaging | Tray | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 5 (Power) | |
| Number of Rows | 1 | |
| Shell Size, Connector Layout | 3 (DB, B) - 5W5 | |
| Contact Type | Power | |
| Mounting Type | Through Hole, Right Angle | |
| Flange Feature | Housing/Shell (M3) | |
| Termination | Solder | |
| Features | Board Lock, Grounding Indents, Mounting Bracket | |
| Shell Material, Finish | Steel, Tin Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | 300V | |
| Current Rating | 30A | |
| Housing Material | Thermoplastic | |
| Color | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DBL5W5P500H30LF | |
| Related Links | DBL5W5P, DBL5W5P500H30LF Datasheet, FFF Distributor | |
