ITT Cannon, LLC DBMM9W4SF179A
- Mfg. Part Number
- DBMM9W4SF179A
- Manufacturer
- ITT Cannon, LLC
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 9 (5 + 4 Coax or Power) Position Through Hole Wire Wrap
- Datasheet Download
- DBMM9W4SF179A.pdf
Availability of DBMM9W4SF179A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.69160
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DBMM9W4SF179A, we specialize in ITT Cannon, LLC all series electronic components. DBMM9W4SF179A can be shipped within 24 hours after order. If you have any demands for DBMM9W4SF179A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DBMM9W4SF179A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DBMM9W4SF179A
| Internal Part Number | EIS-DBMM9W4SF179A | |
| Lead Free Status / RoHS Status | Vendor undefined / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | MIL-DTL-24308, Combo D®, D*MM | |
| Packaging | Bulk | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 9 (5 + 4 Coax or Power) | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 3 (DB, B) - 9W4 | |
| Contact Type | Signal and Coax or Power (Not Included) | |
| Mounting Type | Through Hole | |
| Flange Feature | Housing/Shell (Unthreaded) | |
| Termination | Wire Wrap | |
| Features | Shielded | |
| Shell Material, Finish | Steel, Yellow Chromate Plated Zinc | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 150°C | |
| Voltage Rating | - | |
| Current Rating | 7.5A | |
| Housing Material | Polyester | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DBMM9W4SF179A | |
| Related Links | DBMM9W, DBMM9W4SF179A Datasheet, ITT Cannon, LLC Distributor | |
